Fully compatible with Oval chainrings Absoluteblack Oval Bashguard is the only guide on the market that is designed specifically for Oval chainrings. Extremely light and versatile, the Oval Bashguard secures the chain movement at every single crank position. Special GF polymer composite bash plate can withstand even aggressive enduro use, keeping the chainring safe from impacts. At the same time it is the lightest guide of its kind on the market.
Absoluteblack Oval Bashguard is the only guide on the market that is designed specifically for Oval chainrings. Extremely light and versatile, the Oval Bashguard secures the chain movement at every single crank position. Special GF polymer composite bash plate can withstand even aggressive enduro use, keeping the chainring safe from impacts. At the same time it is the lightest guide of its kind on the market.
Our Oval Bash Guide™ can accommodate any chainline between 48-53mm. That means it fits from 1X setup with 49mm chainline to Boost specific 52mm chainline and much more. Chainline is adjustable in 0.5mm increments, with 4 included spacers 0.5, 1, 2 and 3.5mm
|
Size (Mass +/-1g): |
*69g including ALL TITANIUM hardware |
|
Fits to: |
ISCG05 mount |
|
Suitable for: |
XC, Trial, Enduro, Agressive Enduro |
|
Compatibility |
any 1x10, 1x11 or 1x12 drivetrain with AB oval or round chainring |
|
Chainline |
48-53mm (Boost compatible) by every 0.5mm using 4 spacers (included) |
|
Capacity |
26-34T Oval or 28-36T Round |
|
Material |
Backplate: 7075 aluminium, Cage and bash plate: GF + PA66 polymer composite, Bolts: Titanium Torx T25 |
|
In the box |
complete bash guide; chainline spacers set (0.5, 1, 2, 3,5mm); 3x titanium M6 torx T25 bolts |
